SKOPE ReFlex 1 Solid Door Upright Freezer
The SKOPE ReFlex RF7.UPF.1.SD is a high-performance commercial upright freezer designed for demanding foodservice environments requiring reliable frozen storage in a compact footprint. Featuring robust stainless steel construction, a top-mounted removable freezer cartridge and smart connectivity capability.
Single Door Upright Freezer
363 L
Freezer
The SKOPE ReFlex RF7.UPF.1.SD is a high-performance commercial upright freezer designed for demanding foodservice environments requiring reliable frozen storage in a compact footprint. Featuring robust stainless steel construction, a top-mounted removable freezer cartridge and smart connectivity capability.
| Model |
SKOPE – RF7.UPF.1.SD |
| Dimensions (WxDxH) |
680 x 760 x 1985 mm |
| Weight/Volume (net) |
122 Kg / 363 L |
| Temperature range |
-21°C to -18°C (adjustable with SKOPE-connect -26°C to -12°C) |
| Max ambient temperature |
+40°C |
| Energy consumption |
7.40 kWh/24 h |
| Ventilation requirements |
No ventilation required on sides, back or bottom. 300mm clearance require above unit |
| Refrigeration |
R290 |
| Voltage |
230v / 50hz / 1ph |
| Current draw / nominal capacity |
4.0 amp / 550 watts |
1 Solid Door Upright Freezer
The SKOPE ReFlex RF7.UPF.1.SD is a high-performance commercial upright freezer designed for demanding foodservice environments requiring reliable frozen storage in a compact footprint. Featuring robust stainless steel construction, a top-mounted removable freezer cartridge and smart connectivity capability, this model provides dealers and resellers with a dependable freezing solution for hospitality, healthcare, education and contract catering operations across the UK.
Built for Professional Commercial Kitchens
Constructed with 304 AISI stainless steel interior and exterior, the RF7.UPF.1.SD is engineered to withstand the rigours of busy professional kitchens. The coved internal floor improves hygiene and simplifies cleaning, while the self-closing, lockable solid swing door provides secure frozen storage.
The door is reversible and supplied right-hand hinged, offering installation flexibility depending on site layout. With external dimensions of 1985mm (H) × 680mm (W) × 760mm (D) (with castors fitted), the cabinet provides substantial frozen storage while maintaining a compact footprint suitable for commercial kitchen layouts.
Powerful Frozen Storage Performance
Engineered for consistent freezing performance in demanding environments:
- Temperature range: -21°C to -18°C (adjustable via SKOPE-connect™ from -26°C to -12°C)
- Maximum ambient temperature: 40°C
- Refrigerant: R290 natural refrigerant (94g)
- Energy consumption: 7.40 kWh per 24 hours
- GEMS Class: 5L1
The high ambient rating ensures reliable freezing performance even in hot commercial kitchens.
Top-Mounted Removable Freezer Cartridge
The RF7.UPF.1.SD incorporates a top-mounted integral removable freezer cartridge, simplifying servicing and reducing maintenance downtime.
For dealers and service engineers this offers:
- Faster service access
- Reduced disruption during maintenance
- Lower lifetime servicing costs
- Improved operational uptime for operators
The modular refrigeration design allows efficient servicing without removing the cabinet from its installed position.
Smart Connectivity as Standard
The RF6.UBR.1.SD features the SCS Connect controller, compatible with SKOPE-connect™ via Bluetooth wireless technology.
For dealers and multi-site operators, this enables:
- Remote temperature monitoring
- Data visibility for compliance reporting
- Improved food safety assurance
- Reduced service risk through proactive monitoring
Connectivity adds measurable value, particularly for national chains, facilities managers and healthcare operators requiring temperature control documentation
Flexible Internal Storage Configuration
- 1 self-closing solid swing door
- 5 adjustable height shelves
- Door-activated LED interior lighting (1200mm, 12W)
- Net storage capacity: 363 litres
- Gross storage capacity: 469 litres
The tall cabinet design provides generous frozen storage capacity while maintaining organised product access.
Installation Versatility
Designed for simple specification and installation:
- 220–240V single phase supply
- Supplied with 13 amp plug and 2m lead
- Supplied with removable castors
- Optional height-adjustable legs (1995mm–2035mm)
- No plumbing required
Ventilation clearance required:
- 300mm clearance above cabinet
- No side, rear or bottom clearance required
Related SKOPE products
A Reliable Addition to Your Refrigeration Portfolio
As part of the SKOPE ReFlex refrigeration platform, the RF7.UPF.1.SD provides dealers with a robust upright freezer solution that complements the wider ReFlex range of underbench refrigeration equipment.
Key dealer benefits include:
- Compact 680mm wide upright freezer footprint
- High 40°C ambient performance rating
- Natural refrigerant compliance
- Removable freezer cartridge for simplified servicing
- Smart connectivity capability
- Durable stainless steel commercial construction
The RF7.UPF.1.SD delivers reliable freezing performance, energy efficiency and service-friendly design, making it ideal for demanding commercial kitchen environments.
